TOA ZW-G10CB-AS Portable Amplifier offers reliable performance, clear, powerful sound, and is simple to operate. This portable sound system is equipped with an audio music player that allows music to be played from CD, USB or SD/MMC card and is simple to operate.
| Power Source | AC In: 220-240V, 50/60 Hz DC In: 12V 1A, Max. 18V DC : 12V/2.3Ah (Rechargeable Battery) |
|---|---|
| Power Consumption | AC : 20W, 0.1A (at rated output) DC : 30W, 1.6A (at rated output) |
| Output Power | 20W Max. |
| Frequency Response | 60 Hz – 20 kHz (±3 dB) |
| Distortion | Less than 5% |
| Inputs | Mic 1 & 2 : -40dB* unbalanced 5kΩ, 2 Pole-Phone Jack Aux In : -20dB* unbalanced 10kΩ, RCA Pin Jack |
| Outputs | Audio Out: -25dB* Unbalanced 40kΩ, RCA Pin Jack Speaker Out: 8-16Ω, RCA Pin Jack |
| Sources | Handheld Microphone, Frequency Range 180-200MHz, RF Power Output<10mW —————————————————————————————————– Body Pack Microphone (can be used with tie clip Mic or Headset Mic) Frequency Range 180-200MHz, RF Power Output<10mW —————————————————————————————————– USB Player (support to 32GB), recording function Type of file (MP3 file and Wav File) —————————————————————————————————– SD/MMC card player (support up to 32GB), recording function Type of file (MP3 and Wav File) —————————————————————————————————– Bluetooth connection, class 2, Freq: 2400-2483.5 MHz, Ch:0-78 max. RF Transit power +4dBm —————————————————————————————————– Cassette Player, recording function —————————————————————————————————– FM radio (88-108MHz) |
| Controls | 2 Mircophone Gain Controls 1 Aux Gain Controls 1 MP3 Gain Conotrols 1 Echo Controls 1 Tone Conrtols 1 Power ON/OFF Switch |
| Indicators | 1 LED Display 1 LED Charge 1 LED Bat Low 1 LED Power 1 LED RF1 1 LED RF2 1 LED Rec ( for USB/SD card) 1 LED Record Cassette |
| Battery Live | Approx 5 Hours, Continuous Music |
| Charging Time | 12 hours, 12V/2.3 Ah, Lead Acid Battery, 1 pcs |
| S/N Ratio | 60 dB or more |
| Antenna | Rod Antenna |
| Speaker | 6* Cone (150mm), 4Ω, Full Range |
| Dimensions | 234 (W) × 341 (H) × 180 (D) mm, (9.21″x13.42″x7.08″) |
| Weight | 3.8 kg |
| Accessory | Power card (1.5m)…1 Remote control and inside the battery type CR 2025 3V…1 Handheld Wireless Mic …1 Body Pack Wireless Mic …1 Headset Mic …1 Tieclip Mic…1 |
